- Features and Functions
•Class-AB, Full-Range Mono Amplifier
•Signal to noise ratio of over 110dB
•Coupled the output drivers
•Highest HFE (Gain) Sanken selected output devices
•Differential balanced input stage
•0.1% resistors for lowest possible noise floor
•TI LME49720 (BJT) op-amps on the inputs
•TI LME49720 (BJT) op-amps in the signal path
•WIMA MKS2 series caps in the signal path
•Extremely low ESR caps throughout
•Proprietary patented RCA connectors
Specifications
•Power @ 4Ω: 1000 watts
•Power @ 2Ω: 2000 watts
•THD @ Rated Power < 0.05%
•Signal to Noise Ratio > 110dB
•Frequency Response 10Hz to 30,000Hz ±1dB
•Input Sensitivity 1v to 9v
•Dimensions in mm: 190(W) x 62(H) x 482(L) Overall: 190(W) x 62(H) x 518(L)
