- •DSP Processor: Cirrus Logic CS47048
•Power: 150 MHz/32 bit/192 KHz
•8-Channels IN, 8-Channels OUT
•ADC: Cirrus Logic CS47048 32 bit/192 KHz
•ADC Dynamic Range/THD: 108 dB/-98 dB
•DAC: Cirrus Logic CS8422 24 bit/192 KHz
•DAC Dynamic Range/THD: 140 dB/-120 dB
•Low level (Pre)/Sensitivity: 1-5 VRMS
•High Level (Spk In)/Sens.: 2-20 V
•Optical Digital IN: 24 bit-192 KHz
•Coaxial Digital IN: 24 bit-192 KHz
•Freq. Response (-3dB): 10 Hz – 22.5 KHz
•S/N Ratio only DSP Digital Input: 110 dBA
•S/N Ratio only DSP Analog Input: 106 dBA
•THD+N only DSP Digital Input: 0,002 %
•THD+N only DSP Analog Input: 0,005 %
•Crosstalk at 1 Khz only DSP: 90 dB
•F/R EQ: 1-6 ch Gr. & Par./31 poles
•Effect EQ: 7-8 ch Gr. & Par./11 poles
•Mute/Solo: Yes, each channel
•Time Align. (Range/Steps): 0/15 ms / 0.02 ms
•Max Delay (Cm/Steps): 515 cm / 0.68 cm
•Polarity: 0/180°
•Remote Control included
•HD-BT Streaming (with optional HD-BT)
•PC/Display Connection: USB/6-pin Mini DIN
•Unit Dimensions: 213(W) x 113(L) x 50(H)
