- Features and Functions
•4-Channel, Full Range, Class A/B
•SQ Upgrades: Op-amps, Caps, Etc.
•Tiffany style Panel Mount RCA’s
•RCA and Speaker Level Inputs
•Variable input gain control
•Variable electronic crossover
•Auto-on with Speaker level inputs
•New aluminum chassis
Specifications
•Power @ 4Ω: 4 x 70 watts
•THD @ Rated Power < 0.1% THD
•Power @ 2Ω: 4 x 95 watts
•Power Bridged @ 4Ω: 2 x 190W RMS
•Signal to Noise Ratio > 95dB
•Channel Separation >60dB
•Frequency Response 15Hz to 30KHz ±1dB
•Input Sensitivity .25v to 5v
•Dimensions in mm: 160(W) x 58(H) x 300(L) Overall: 160(W) x 58(H) x 325(L)
