Features and Functions
•Mono Class D Linkable, bass amplifier,
•Stable into 1 Ohm (2 Ohm w/2 amps Linked/Strapped)
•PWM MOSFET power supply
•24 dB Variable low pass (LPF) crossover
•12 dB Variable bass boost equalization
•0 – 180 degree variable phase shift
•24 dB Variable subsonic filter
•Selectable master and slave operation for Linked (strapped) amplifier operation
Specifications
•Power @ 4Ω: 800 watts
•Power @ 2Ω: 1400 watts
•Power @ 1Ω: 2100 watts
•Linked @ 2Ω: 3600 Watts
•THD @ Rated Power < 0.05%
•Signal to Noise Ratio > 90dB
•Damping factor: > 350
•Efficiency: 86%
•Input Sensitivity .2v to 8v
•Dimensions in mm: 190(W) x 62(H) x 450(L) Overall: 190(W) x 62(H) x 486(L)
